PKT-300ENew
PMR446 Compact UHF FM Transceiver – EU and UK use
Key Features
| Lightweight and Easy-to-Use |
| 500 mW ERP Transmit Power, up to 24 Hours of Operation |
| Superb Audio Quality |
| 16 Preset Channels with Scan |
| LCD and LED Visual Information |
| Privacy Talk |
| Quiet Talk (QT) and Digital Quiet Talk (DQT) |
| Internal Voice Operated Transmission (VOX) |
| Radio Management |
| Tough Reliability |
Supplied With
| Battery | Yes, , KNB-81L Li-ion Battery Pack |
| Belt Clip | Yes, KBH-20 |
| Charger | Yes, KSC-50CR Charger Pocket with KSC-44SL AC Adapter |
| Instruction Manual | Yes, In English, Spanish, German, French, Dutch & Italian. In addition, Turkish, Greek & Portuguese language versions are available as downloads in PDF format. |
PMR General Features
| 2-colour LED (Red, Green) | Yes |
| Battery Saver Mode | Yes |
| Busy Channel Lock-out | Yes |
| Calling Alert | Yes |
| Compact Design | Yes |
| Earphone Jack Socket | Yes, 3.5mm |
| Enhanced Kenwood Audio | Yes |
| Key Lock | Yes |
| Programmable Function Keys | 2 Programmable Function Keys |
| PTT Proceed Tone | Yes |
| PTT Release Tone | Yes |
| Scan | Yes |
| Tone Alert | Yes |
| VOX | Requires suitable VOX Headset |
| Windows PC Programming and Tuning | Yes |
Applicable Standards
| IP52 | Yes |
| MIL-STD 810 C/D/E/F/G/H | Yes |
Technical Specifications
| Frequency Range | 446.0 - 446.2 MHz |
| Number of Channels | 16 |
| Channel Spacing | 12.5 kHz |
| Battery Life | with KNB-81L: 18 Hours (5-5-90, Battery Saver Off) with KNB-81L: 24 Hours (5-5-90, Battery Saver On) |
| Frequency Stability - ± 2.5 ppm | Yes |
| Operating Temperature Range | -10 °C to + 60 °C |
| Dimensions | 50 x 98 x 27 mm (W x H x D) - with KNB-81L, projections not included |
| Weight (net) | 140 g |
Receiver Specifications
| Audio Output | 300 mW |
| Intermodulation | 60 dB |
| Selectivity (Analogue) | 60 dB |
| Sensitivity - EN 20 dB SINAD | 0.28 µV |
| Spurious Response Rejection | 70 dB |
Transmitter Specifications
| RF Power Output | 500 mW (ERP) |
| Audio Distortion | Less than 5% |
| FM Hum & Noise | 50 dB |
| Spurious Response (EIA) | -36 dBm ≤ 1 GHz, -30 dBm > 1 GHz |
