AP-300-B
  • AP-300-B

Additional Images

AP-300-B

Compact Hifi System with Bluetooth receiver, CD, Radio USB Host function.

Portable and simple to operate audio system, compact one-body design. Easy to carry, fits smoothly in many interiors. Only 1 cable required, just hook up the powercord and you can sit back, relax an listen to music from many different sources, with a natural sound.
  • CD DA / CD-R/RW
  • USB-A Terminal (USB Host)
  • MP3
  • WMA

Key Features

Enjoy wireless playback with built-in Bluetooth
Simple top panel design for usability & comfort
Made for iPod, iPhone
All-in-one design complete with CD, radio and USB port

General Features

Remote Control44-key Standard Remote
Automatic Power Save (A.P.S)Yes
Dimmable DisplayYes

Tuner Features

Tuner (AM/FM)Yes
Radio Data SystemYes
Program Type (PTY)Yes
Number of Presets (DAB)40

Audio Features

Equalizer6 Presets (Pop/Classic/Rock/Jazz/Game/Flat)
X-Bass / Bass BoostYes

Bluetooth General Features


Playable Media

CD DA / CD-R/RWYes
MP3Yes
ID3 TagYes
WMAYes
AACYes

CD Features

CD DA / CD-R/RWYes
MP3Yes
WMAYes
CD TextYes
Program PlaybackYes
Repeat PlaybackOne / All
Random PlaybackYes

Digital Inputs/Outputs

USB-A Terminal (USB Host)Yes
Optical Audio Input/Output1 / -

Analogue Inputs/Outputs

Headphone Jack (3.5 mm)Yes
Front Auxiliary Input Jack (3.5mm)Yes
75 Ohm FM Antenna ConnectorYes
AM Antenna ConnectorYes

Amplifier Features

Maximum Stereo Output Power2 x 20 Watt
Digital AmplifierYes

Audio Specifications

Effective Output Power2 x 20 Watt (1kHz, THD 10%, 8Ω)
Input Sensitivity/Impedance: Line (AUX)300mV / 10kΩ

Tuner Specifications

FM Tuning Frequency Range87.5 ~ 108MHz
Antenna Impedance75 Ω unbalanced
AM Tuning Frequency Range531 ~ 1609kHz

USB Specifications

FormatUSB Host (Playback)
USB Standard2.0 Full Speed
MP3 Sampling Frequency (Stereo)32/44.1/48kHz
MP3 Bitrate (CBR/VBR)32 kbps to 320 kbps
WMA Sampling Frequency (Stereo)32/44.1/48kHz
WMA Bitrate (CBR/VBR)32 kbps to 320 kbps
ID3 tagVersion 1.0/1.1/2.2/2.3/2.4
Maximum Folders255
Maximum Files3000
Maximum Current Supply1000mA
File SystemFAT 16 / 32
Maximum number of displayable characters64 ID3TAG Ver. 1.0/1.1/2.2/2.3/2.4
iPod / iPhone USB connectionYes
Compatible iPod / iPhoneiPhone 5S, iPhone 5C, iPhone 4S, iPhone 4,
iPhone 3GS, iPhone 3G, iPod touch (1st - 5th generation), iPod nano (2nd - 7th generation) iPod touch (version 3.1.3)

Speaker Specifications

Peak Input Power20 Watt
Impedance8Ω
SpeakerFull-range 70mm Bass-reflex type

General Specifications

Display TypeDot Matrix

Power Specifications

Power Consumption18 Watt
Stand-by Power Consumption (less than)1 Watt
Adaptor AC-DCInput 100-240VAC 50-60Hz 1.5A 0.5A Output 18VDC 3.35A

Dimensions & Weight

Dimensions Body (WxHxD)360 x 199 x 225 mm
Weight Body (Net)2.9kg
